Time Relay / Emergency Stop
SAFEONE DNSR
The DNSR time relay is ideal for enabling two control circuits, optionally preconfigured with release-delayed or pull-in-delayed contact outputs. With the 33SR20 variant, the time delay can also be set directly on the device using two potentiometers.
The DNSR emergency stop relay is ideal for monitoring an emergency stop circuit. Preconfigured with release-delayed contact outputs and instantaneous non-delayed contacts.
General Data
Degree of contamination | 2 |
Overvoltage category | III |
Current consumption at 24V | 40mA in rest position 70mA in active position |
Protection (Casing and Terminals) | IP20 |
Protection (Installation Site) | min. IP 54 |
Power consumption at A1/A2 | 1,6W |
Casing Material | Polyamid PA non-reinforced |
Operating Voltage Ub | 24V DC (±10%) |
Rated surge voltage/ insulation | 4 kV |
Rated insulation voltage | 13/14, 47/48 - 250V AC 24, 34 - 30V AC |
Terminals | Screw terminals |
Conductor cross-section | 0,25 - 1,5 mm^2 |
Conductor cross-section AWG | AWG 24…16 |
Conductor type | Flexible with ferrule |
Wire stripping length | 8mm |
Tightening torque min/max | 0,5Nm/0,6Nm |
Input Data
Voltage outputs | S11, S22 |
Voltage | 15V DC ± 0.5V |
Outputs
Voltage outputs | S11, S22 |
Voltage | 15V DC ± 0.5V |
Contact outputs | 13/14, 47/48 | 24,34 |
Contact Material | AgNi | - |
Minimum switching current | 10mA | 3mA |
Maximum switching current *Limitation due to design | 6A* 1A | 0,5mA |
Breaking capacity according to IEC60947-5-1 | DC13: 2A/24V DC13 bei 0,1 Hz: 4A/24V AC15: 3A/250V | - |
Mechanical service life | ≥ 10^7 Switch cycles | ≥ 5 x 10^7 Switch cycles |
Contact fuse protection | 5 A gL/gG | 5 A gL/gG |
Response/relapse time typical | 10 ms / 6 ms | 10 ms / 6 ms |
Environmental Data
Operating temperature | -10 °C to +60 °C |
Storage temperature | -40 °C to +85 °C |
Height | < 2000m above Sea Level |
Shock resistance | 15g, all 3 axes |
Block Diagram
Safety-relevant Parameters according to DIN ISO 13849-1
Stop Category according to IEC 60204 | 1 |
Category according to DIN ISO 13849 | 3 |
Performance Level | d |
MTTFd [a] | 98 |
PFHd | 4,3E-08 |
Service Life | 240 months |
Contact Service Life
DNSR 2R: Time Delay Relay Manual
DNSR 2R2: Time Delay Relay Manual
DNSR 2R: Emergency Stop Relay Manual
DNSR 2R: Time Relay – EC declaration of conformity
DNSR 2R2: Time Relay – EC declaration of conformity
DNSR 2R: Time Relay - EC declaration of conformity
Compatibility
- Energy separation of drives
- Unlocking protection
- Can be used in safety circuits according to VDE0113, part 1 with maximum category 3 / PLd according to ISO 13849-1
Branchen
- Woodworking
- Metalworks
- Construction
- Spindles
- Centrifuges
- and many more...
Your advantages summarised.
2 control circuits with one single-channel and one dual-channel contact each.
2 terminals for time setting release, provided that the two-channel contacts are adjustable via potentiometer.
Choice of instantaneous, off-delayed or on-delayed contacts.
Individual time settings are parameterised ex works according to customer specifications. Optionally, the delay times of the safe contacts can be set via a potentiometer.
All contacts are designed as NO. The single-channel contacts can be electrically designed as NC by re-parameterisation.
The connection panel is attached to the side of the unit.
The pluggable terminals are interchangeable.
Inputs and outputs are checked for plausibility.
